Audio-Video |
|
|
Video Compression |
MPEG4 |
|
|
Frame |
25fps(PAL),30fps(NTSC),D1/2CIF/QCIF |
|
|
Format |
160*120(QQVGA),320*240(QVGA),640*480(VGA) |
|
|
Sensor |
SONY CCD |
|
|
Image |
automatic exposure,Auto White balance |
|
|
Adjustment |
Support image level and invertsion browse |
|
|
Color |
Brightness, saturation,contrast adjusting |
|
|
Audio |
G.711,G.726,G.723.1,G.729 |
|
|
Net Work |
|
|
Data frequency |
Dynamically adjusting the frame speed rate and
picture quality according to network's actual bandwidth |
|
|
|
Input |
Ethernet,ADSL,Cable modern,light fibre，dialing |
|
|
Protocols |
Support TCP/IP,SMTP,HTTP,FTP,PPPoE,DHCP |
|
|
UPnP |
Protocols with no driving，support zero-collocation
and function of self-lookup. |
|
|
DDNS |
Reflecting IP address to certain domain name |
|
|
SMTP |
Send pictures via email |
|
|
WEB |
Inserting web server, Manage by IE |
|
|
wireless |
Standard IEEE802.11b/g protocols,can work with common
wireless Router |
|
|
Security Management |
|
|
Motion detection |
be trigger when the movement rate more than standard rate |
|
|
Alarm |
Send Email or upload video file by FTP |
|
|
Recording |
standard Media Player storage format,support common video
player on PC，support time label |
|
|
Snapshot |
Real-time surveillance and snatching pictures during
review the video |
|
|
Browse |
Support 20 users browse on line |
|
|
Accessing |
long-distance control by IE，Multi-images control |
|
|
Safe-conduct |
Users use the correspond code system to control and manage |
|
|
WEP |
Wireless Input Authenticate |
|
|
Upgrade On-line |
Inserting real-time operating system,support software
update on line |
|
|
PTZ |
RS485，Pelco-P/Pelco-D protocols |
|
|
Language |
Chinese/English optional |
|
|
Reset |
Renew by pressing the reset button |
|
|
Expanding |
Developing SDK for system opening up |
|
|
Hardware |
|
|
GPIO |
can work with other surveillance equipments
through input and output |
|
|
Stability |
High quality apparatus, perfect testing, steady operation
with long-time,embeded operating system |
|
|
|
Power Supply |
DC12V/1.5A,IEEE802.3af Ethernet supply current
with long-distance |
|
|
Operating Conditions |
0-50° C;humidity10%-90% |
|
|
Housing |
high density alloy,Waterproof and dustproof |
|
|
Focus |
Open the head to adjust in the condition of waterproof |
|
|
Auto IR leds |
IR Led turn on auto at dark condition |
