Ceramic Intalox Saddle
Introduction Saddles are used in two main fields but have different properties depending on their application. The first field is the chemical and petrochemical industries and the second is in environmental areas such as RTO equipment. The first saddle is for chemical and petrochemical, the technical data as following: Chemical composition
SiO2
Al2O3
Fe2O3
CaO
MgO
K2O+Na2O
Other
>73%
17-23%
<1.0%
<0.5%
2-4%
<0.1%
Physical properties
Index
Value
Specific gravity(g/cm3)
2.3
Water absorption(%)
<0.3
Acid resistance(%)
>99.6
Max operating temp.(℃)
1100
Porosity(%)
<1
Moh’s hardness(scale)
>6.5
Thermal conductivity(w/m.k)
0.9-1.0
Specific heat(j/kg℃)
850-900
Technical data
Spec.(inch)
Sepc.(mm)
W(mm)
H(mm)
L(mm)
T(mm)
Number per m3
Bulk density (Kg/m3)
Free volume (%)
Surface area (m2/m3)
1/4”
6
4.5
9
1.5
4,050,000
1050
54
3/8”
10
8
16
2
1,560,000
900
63
825
1/2”
12
20
2.5
610,000
780
68
647
5/8”
24
269,000
700
71
535
3/4”
19
14
28
3
146,000
670
75
350
1”
25
21
38
4
59,000
250
1.5”
30
60
19,680
580
80
180
2”
50
40
5.5
8,243
550
79
120
3”
76
57
114
2,400
530
91
Dimension
Normal size
Diameter of Deck (mm)
Outside diameter(mm)
Height(mm)
Wall thickness (mm)
Width(mm)
6mm
6±2.0
9±2.0
4.5±2.0
1±0.5
10mm
10±2.0
16±2.0
8±2.0
1.5±0.5
12mm
12±1.0
20±1.4
10±1.0
2.0±0.45
16mm
16±1.0
24±1.5
2.0±0.5
12±2.0
19mm
19±1.5
28±2.0
14±1.0
2.5±0.5
14±2.0
25mm
25±1.5
38±2.0
19±1.0
3.0±0.5
20±2.0
38mm
60±3.0
30±1.5
4.0±1.0
30±2.5
50mm
50±2.5
80±4.0
40±2.0
5.0±1.0
40±3.0
76mm
76±4.0
114±4.0
57±.0
9.0±1.0
57±4.0
