Aluminium Kitchen Roll Auto Production Machine

^{Machine Features: - Fully auto core loading, gluing, slitting and rewinding of foil rolls - Complete with meter cutting length control - Combination of both Western & Asian Technologies on complete production and control - With auto feeding aluminium foil speed control, alignment and adjustment - High productivity and user-friendly - Complete with all safety features - Customized core width meeting to respective buyer’s requirement}

^{Technical Data:}

^{Raw materials aluminium foil thickness     -      0.01mm to 0.02mm}

^{Raw materials widt                                    -      250 to 600mm roll width}

^{Maximum unwind roll diameter                  -      600mm diameter}

^{Raw material mother roll core id               -      75 to 76mm (core id)}

^{Finished Roll Rewinding Core id              -      24mm, 30mm, 38mm}

^{Slitting length finished roll control            -      3M to 330M}

^{Production Speed (basing 5M length)      -      Between 7-10 rolls / minute}

^{Unloading magnetic power brake             -      25N.M}

^{Winding magnetic power clutch                -      12N.M}

^{Electrical Power & Supply                         -      4KW}

^{Weight of machine                                    -      1500kg}

^{Dimension of machine (L x W x H)             -     4164mm x 1100mm x 1820mm}

^{For more details and vidio presentation,please contact our export oversea office in China!}
