flat automatic computer Jacquard needle loom(taiwan technology)

Detailed Product Description

Specifications:

1) The open warp employs the horizontal structure design with stable frame operation. With low noise, it can enlarge the stabilizations and reliabilities when running the machine.

2) Equipped with the gathering electromagnetism valve and small bulk, the action is sensitive when working.
3) The jacquard bibcock is designed with the most advanced

micro-electronic technology. The structure is simple and compact, and the installation and the maintenance is convenient.

4) The tensity of the longitude is controlled automatically, very advanced and reasonable.

5) The fabric pattern can be seen in the windows on lines, directly and clearly.

6) The quick-type healed wire installing and removing structure reducing the labor intensity of the operators and maintainers.

7) The purpose-made CAD Embroider System is convenient for operation with self-locking function.

8) The control system is equipped with programmable program and data system, which can record and demonstrate different production figures, automatic display the trouble and the reasons, and also can timely duplicate the data information in case of the special circumstance.

Main technical data:

1)Modle: 8/30; 6/45; 4/63; 2/110

2)Numbers

Of Strips: 8; 6; 4; 2;

3) The Width

Of Reed

（Mm）: 30; 45; 65; 110;

4) Numbers

Of Shedding

Flames: 12; 12; 12; 12;

5)Numbers

Of Pattern
