Sinoway Wheel loader SWL30F

Model SWL30F
Bucket capacity 1.7m3
Wheel base 2750mm
Tread 1800mm
Min. Ground clearance 370mm
Rated load 3000kg
Max. Breakout force 75Kn
Dump reach 1020mm
Dump heigh 2870mm
Lifting time of bucket 5.1s
Lowering time of bucket 3.1s
Dumping time 1.1s
Max. Travel speed 36km/h
Engine: Chinese Deutz
Rated power 92kw/2200rpm
Operation weight 9830kg
Overall dimension 6840x2250x3220mm
