Proximity access control system ST-780

1.Multiple waterproof design with built-in door bell button.it is suitable for both indoor or outdoor use.
2.LED indicator to display time and card number.it displays setting modes when it is used for stand alone setting.
3.When connecting with computer,it can be used for data inquiry and function setting simutaneously.(Door open/close.start alarm system,etc).it can also operate solely  to manage acccess control.
4.Function setting can be done by computer or reader itself.(Single registration or deletion,door open time.etc).
5.The capacity data input/output can reach up to 5000 by single reader operation.when linking with computer,its data input/output capacity is unlimited.
6.Main reader has 2000 card registrations capability.each card is able to do self-setting for personal password and effective in/out time.
7.Main reader has 49 units of time zone.Each time zone unit also has 5 time ranges for self-setting by user.
8.Frequence:125khz or 13.56 mhz
9.Proximity range:3~7cm according to the types of card and frequency of use.
10.Dimensions:140LX60WX30H
11.Current:DC12V/180mA,Operation temperature:0~70,Humidity:85%Rh Max.
