Chenille Machine

Detailed Product Description

Main technology parameter

Machine type	JC-80
Spindle Gauge	200mm
Spindles per frame	The spindles can be combined to 80 on the basis of 20spindles
Internal Diameter of Ring	112mm
Lift Stroke	280mm(can be adjusted)
Lift Speed	Adopt imported inverter and PLC(programmable controller)to control it
Count	1-7Nm
Roller Diameter	29.5mm
Spindle Speed	4500-5400RPM
Rotor Speed	5200-16500RPM
Production Efficiency	5-10.5m/min
Twist Direction	Chenille yarn is S twist,Z twist is for customers option
Drive Style	Lift motion is driven by one motor
Total Power	4.1kw-3.0kw ( 20 spindles)
Overall dimension Upon the basis of 20spindles	4500x1700x2600
Every 10 spindles	2040x1700x2600
Air-absorb equipment	can be installed according to customers requirement
