Sinoway Mini Wheel Loader SWL10F

 Model : SWL10F
 Rated load :1000kg
 Bucket capacity :0.5 m3
 Brakeout force:  35Kn
 Max.drawbar pull:  30Kn
 Tipping load:  20Kn
 Travel speed
 1st forward:  0-10km/h
 2nd forward:  0-25km/h
 1st reverse:  0-10km/h
 2nd reverse:  0-25km/h
 Dump height:  2250mm
 Rasing time for bucket : 5.2s
 Lowering time for bucket:  3.4s
 Engine:  495k-3
 Rated power:  40.4kw/2400rpm
 Grade ability:  60%
 Operation weight:  4500kg
 Overall dimension:  4480x1800x2644mm

Post Date:	9/2/2009
Expiry Date:	8/28/2010
