Sinoway Mini loader SWL16F

 Model : SWL16F
 Rated load : 1500kg
 Bucket capacity:  0.9 m3
 Brakeout force:  38Kn
 Max.drawbar pull:  33Kn
 Tipping load:  30Kn
 Travel speed
 1st forward:  0-10km/h
 2nd forward : 0-25km/h
 1st reverse:  0-10km/h
 2nd reverse:  0-25km/h
 Dump height:  2460mm
 Rasing time for bucket : 5.2s
 Lowering time for bucket : 3.4s
 Engine:  495k-3
 Rated power:  40.4kw/2400rpm
 Grade ability:  60%
 Operation weight : 5100kg
 Overall dimension : 4829x1950x2654mm

Post Date:	9/16/2009
Expiry Date:	9/11/2010
