Pneumatic Globe Valve

PGV series pneumatic globe valve is avail of the most advanced oversea technology for both raw meal silos, cement depot; particularly is the best replacement of similar import equipment in sealing and discharge linear. It has a good efficiency contrast to similar imported products in the 1000t/d, 2500 t/d and 5000 t/d cement production line. Pneumatic globe valves open and close quickly through the driving force of the cylinder rotation. It plays a role of flow control switcher mainly in powder, grain materials, small particle transmission flow control system; normally it is used with electric flow control valve. PGV series pneumatic globe valve is make electromagnetic valve, rotating cylinder, as its control drive device to control the switch, and is an ideal equipment for flow regulation.



(1). This product has the features as following: open and close flexibly, seal tightly without leakage, the spool and the valve end are hardly worn out; low noise rate and vibration, long service life etc.

(3). PGV series pneumatic globe valve has a pleasing appearance, compact structure, small size, light weight, high sensitivity, non resistance, and no angle limit.

(4). Spool uses high wear performance materials; the ceramic surface is to enhance the sticking property with high-density blanket, and reducing the wear to blanket; arc open outer make material flow without resistance. Spool sealed softly with quality high-density blanket. The adjustment of the seal box can be undergone externally so that to adjust the clearance of the spool and blanket for the purpose of no leakage. The blanket has a long service life, and can be replaced conveniently after worn.



0.4~0.7 Mpa dynamic air source are provided to 2-5 electromagnetic valve of PGV series pneumatic globe valve, supply stable air flow to the dual role rotating cylinder, which led the stem rotate rapidly and then the feedback device send the signal to control center through its rapid open and close acts. With stable air source, the 2-5 electromagnetic valve can make the valve full close and full open.
