AAA Mechanical Squaring Shear

NC Front Gauge

1. Many Kinds and various waya os measurements are possible by 100 points memory .
2. 100  processes are presettable with 0.1mm increment.
3. Multiple process cycle operation is possible by automatic positioning of stopper.
4. As the plate is measured always from the blade line, it has no accumulated error.
5. Work plate handling is light and smooth by free bearings.

Return Conveyor with pilling lifter.

1.  Convenyor supports sheet fromsagging at the pass line to cut accurate.
2. The cut sheet returns back to table by the return funtion and it is convenient to handle in front.
3. Automatic lifter keeps dropping height ahorter and constant to avoid scratch by edge of plate and also turning over of plate.
4. Scrape and trimming edge can be separated by dumper.

Inverse Clamping Device

1. It holds the material by pushing to the upper blade during cutting.
2. When cutting narrow strips, it is effective to reduce bow, twist and camber of the work plate to a considerable extent.

Sheet Support Type DA

1. The versatile sheet support is capable to support and accurately cut thinner and wider plate.
2. The arms are lifted automatically by air cylinder.
