Principle:
Q-Switched Nd:YAG adopts the latest Q-switched model, makes the cure time of laser to be smallest, avoiding damage to the skin. And the skin tissure absorbs the high energy of the certain laser wavelength in instant, and expand and explode to tiny thing easily. Then licked up by the cell and be got out of the body.
Suitable for:
1.1064nm: birth mark, coffee spot, freckle, senile plaque, pigment from outside injure, black, blue tattoo, eye line, eye brown and lip line etc.
2.532nm: red and brown pigment, red spot and mole, capillarectasis and brandy nose.
Specifications
Wavelength: 1064/532nm
Medium: Nd: YAG
Max output energy: 1064nm:800mj±150mj/pulse;
532nm: 250±50mj/pulse
Q-switched Pulse Width: 7±3ns
Light: He-Ne laser(semi-conductor)
Way: seven-joint arm
Temperature: 0--4oC
Repeat Frequency: 1064nm:1,2,3.5.10Hz
532nm:1.2.3.Hz
Aimming Light: 632.8nm
Light way: seven-joint light arm
Controlling way: LCD, micro computer control,
single and double timer
Cooling System: inner water circulation cooling
Working way: Q switched change
Protection System: cutting water and over-load double protection
Power: 110V±11V 60±1Hz or 220V±22V 50Hz±1Hz
Power consume: ≤2.5KVA
Humidity: ≤80%
Environment Temperature: 5--40oC
Package Size: 800×400×750mm
Weight: 75Kg
