diesel forklift

Detailed Product Description

CPCD80H

Units Model:	CPCD80H
Rated Capacity (KG)	8000
Load Center (MM)	600
Lifting Height(MM)	3000
Max Lifting Speed (MM/S)	350
Frame Inclination Front/back (°)	6/12
Max Running Speed Gear/Gearkm/h	12/25
Climbing of a full load (%)	20
Min turning Radius (MM)	4000
Min Space to the ground (MM)	245
Axis distance (MM)	2735
Wheel distance Front(MM) Back(MM)	1530 1500
Front hanging Distance (MM)	695
Standard Fork length (MM)	1200
Motor	Model YC6105 Power(kw) 85 Speed(rpm) 2200
Tire	Front 9.00-20-16PR Back 9.00-16-16PR
Overall size	Length(mm) 5440 Width(mm) 2100 Height to top(mm) 2500 Height to frame(mm) 2590
Transmission form	Hydraulic
Self Weight(kg)	10000
