forklift

Detailed Product Description

CPCD70

Units Model:	CPCD70H
Rated Capacity (KG)	7000
Load Center (MM)	600
Lifting Height(MM)	3000
Max Lifting Speed (MM/S)	350
Frame Inclination Front/back (°)	6/12
Max Running Speed Gear/Gearkm/h	12/25
Climbing of a full load (%)	20
Min turning Radius (MM)	3400
Min Space to the ground (MM)	245
Axis distance (MM)	2355
Wheel distance Front(MM) Back(MM)	1530 1500
Front hanging Distance (MM)	650
Standard Fork length (MM)	1200
Motor	Model 6102/6105 Power(kw) 72.8/82 Speed(rpm) 2200/2300
Tire	Front 8.25-20-16PR Back 8.25-15-14PR
Overall size	Length(mm) 4965 Width(mm) 2100 Height to top(mm) 2500 Height to frame(mm) 2590
Transmission form	Hydraulic
Self Weight(kg)	10000
