KWTMH685 fullautomatic carton windowing and sticking film machine

The machine is mainly applicable for film sticking of various thick windowing ground paper like drug box,cosmetic box,toy box,paper tissue box and gift box.Its head adopts the air-suction pressing sheet feeding with the automatic sizing and film sticking device and the clutch function.Also it can adjust the film length freely and is providedwith an automatic delivery unit.It is easy for debugging with excellent performance

TECHNICAL PARAMETER:
(working speed):5000-10000pcs/h
(applicable paper size):520×420mm
(applicable window size):30×15-220×200mm
(film thickness):0.025-0.05mm
(total machine power):4.5kw
(machine weight):1200kg
(machine dimension-L*W*H):3000×1000×1300mm
