ENGINE

Engine Type

Air cooled, 4-stroke

Air cooled, 4-stroke

Displacement

86CC

107CC

MAX power

4.0KW/7500RPM

6.0KW/8500RPM

MAX torque

5.6.NM/6000RPM

7.0NM/6500RPM

Compression Rate

9.1:1

9.1:1

Cooling

Air  cooling

Air  cooling

Lubrication

Pressure and Splash

Pressure and Splash

Ignition

C.D.I

C.D.I

Starting

Electric starter

Electric starter

DRIVE TRAIN

Final Drive

Chain

Chain

Transmission

Automatic

Automatic

SUSPENSION

Front Suspension

Double A-arm

Double A-arm

Rear Suspension

Swing arm

Swing arm

BRAKE

Rear Brake

Hydraulic disc

Hydraulic disc

Parking

Rear brake

Rear brake

TIRE

Front Tire

AT 18*7-8

AT 18*7-8

Rear Tire

AT 18*9.5-8

AT 18*9.5-8

DIMENSIONS

Length

1520 mm(59.8 in)

1520 mm(59.8 in)

Width

1020 mm(40.2 in)

1020 mm(40.2 in)

Height

970 mm(38.2 in)

970 mm(38.2 in)

Seat Height

730 mm(28.7 in)

730 mm(28.7 in)

Wheel Base

960 mm(37.8 in)

960 mm(37.8 in)

Turn Radius

2,200 mm(86.6 in)

2,200 mm(86.6 in)

Ground Clearance

120 mm(4.7 in)

120 mm(4.7 in)

Dry Weight

113kg(248lb)

113kg(248lb)

Max Speed

55 Km/h

55 Km/h

Electrical

Battery

12V4AH

12V4AH
