Air-cooled ATV/Quad(YG-ATV200ST-3)

Features:
1) Person: 1
2) Maximum speed: 65km/h
3) Mini turning radium: <1,650-+150mm
4) Maximum load capacity: 90kg
5) Engine type: 4-stroke, air-cooled, fully automatic
6) Cylinder: horizontal single
7) Cylinder diameter x work stroke: 71 x 58mm
8) Final drive: chain drive (shaft drive available)
9) Bore x stroke: 52.4 x 49.5mm
10) Piston displacement: 149cc
11) Compression ratio: 9.1:1
12) Max. power: 5.5kW / 8,000+_500rpm
13) Max. torque: 6.6N.m / 6,000+-500rpm
14) Starting method: electric
15) Lubrication: oil injection
16) Transmission: fully automatic, with reverse gear
17) Overall dimensions: 1,484 x 865 x 953mm
18) Wheelbase: 980mm
19) Seat height: 660mm
20) Ground clearance: 108mm
21) Parking brake: mechanical lock
22) Brakes: front dual sealed drum, rear hydraulic disc
23) Tires (front / rear): 19 x 7-8 / 18 x 8-8
24) Ignition: CDI
25) Fuel tank capacity: 7.8L
26) Engine oil capacity: 1.6L
27) Front suspension: double A-arm
28) Rear suspension: swing arm
29) Battery: 12V, 12A

Outer packing:
Carton dimensions: 1,470 x 835 x 770mm
N.W.: 125kg
G.W.: 140kg
