EEC ATV 250cc(YG-250E-A3)

1) Engine type: 150cc, single cylinder, 4-stroke, air-cooled, automatic with reverse
    200cc, single cylinder, 4-stroke, air-cooled/water cooled, manual
    250cc, single cylinder, 4-stroke, air-cooled/water-cooled, four forward speeds with reverse
2) Transmission mode: Chain drive
3) Start way: Electric start
4) Ignition: CDI
5) Rating power:
10.8 kw /8000(r/min）250cc     Max torque: 18 N·m /5500(r/min）250cc
6) Max. Speed: 70km/h 250cc,    60km/h 150cc
7) Wheel bases: 1250mm
8) Min ground clearance: 100 mm
9) Distance between wheels (F/R): 930/770mm
10）Front /Rear tire: 21x 7- 10/ 20x 7- 10
11) Brake (front/rear): Drum/Disc brake
12) Battery: 12V.9Ah
13) N.W.: 158kgs              G.W.: 170kgs
14) Max. Load capacity: 150kgs
15) Overall size: 1680×1150×1160mm
16)Carton size: 1480×845×850 mm
17) Conveyance: 63pcs /40' HQ
