260cc EEC ATV/Quad(YG260E-A2)

Detailed Product Description

Colors : Black | Blue | Green | Red | Yellow

KEY FEATURES:

260cc, chunfeng WATER-cooled engine, 4 stroke, shaft drive, CVT with reverse gear, front/rear disc brake,EEC homologated

Specifications
Engine Type	4 stroke, water-cooled,CVT
Final Drive	shaft drive
Bore x Stroke(mm)	65 x 63
Piston Displacement(cc)	255cc
Compression Ratio	9:1
Maximum Power(kw/r/min)	12.5kw/7500r/min
Max Torque(N.m/r/min)	20.0N.m/5500r/min
Starter Sytem	electric
Lubricaiton	wet sump
Trasmission	C.V.T.
Overall LxWxH(mm)	2150x1212x1190
Packing Dimension LxWxH(mm)	2200x1250x860
Wheel Base(mm)	1265
Seat Height(mm)	865
Overall Height(mm)	190
Ground Clearance(mm)	100
Parking Brake	hydraulic disc, all wheel
Brake(Front/Rear)	single lever hydraulic disc
Tire, Front	AT24x8-14
Tire, Rear	AT24x10-14
Ignition Type	CDI
Fuel Tank Capacity (L)	14
Front Suspension	Macpherson strut with 6in travel
Rear Suspension	progressive rat swing arm with 7 intravel
Max Speed(km/h)	80km/h
Mini Turing Radium(mm)	3277
Max. Load Capacity(kg)	120
Battery Specifiction	12V14Ah
NW(kg)	260
GW(kg)	310
Quantity of Loading	27pcs 40'hq

Conveyance:
Qty/40' HQ: 29pcs
