ROLLERWAY Excavators(SANYI) SY200

Detailed Product Description

Main Technical Parameters:

Specifications
Working weight	Kg	19600
Capacity of excavator bucket	m3	0.8-1.0
Main performance
Travelling speed(high/low)	Km/h	5.5/3.2
Slewing speed	rpm	12.5
Grade ability		70%
Ground specific pressure	kPa	44.8
Bucket capacity	kN	138
Bucket rod capacity	kN	100
Engine
Type		Cummins
Model		6-cylinder, 4-stroke, water-cooling, injetting, turbo charged
Rated power	KW/rpm	101.5(138Hp)/2000
Max. torque	Nm/rpm	556/1350
Displacement	L	5.883
Hydraulic system
Model of main pump		Variable inclined-disc, plunger double-pump
Max. discharge of main pump	L/min	2×208
Pressure of main safety valve	Mpa	31.4/34.3
Travelling hydraulic circuit	Mpa	34.3
Slewing hydraulic circuit	Mpa	25.5
Controlling hydraulic circuit	Mpa	3.9
Capacity of oil tank
Fuel tank	L	340
Hydraulic oil tank	L	239
Engine oil	L	26.3(24)
