Description:
The Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.
Features:
l Complies with IEEE802.3, IEEE802.3u standards.
8 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX.
Supports IEEE802.3x flow control for Full Duplex mode and backpressure for half-duplex mode.
Supports MAC address auto-learning and auto-aging.
LED indicators for monitoring power, link, activity.
Plastic case, desktop
External Power Adapter supply.
Specification:
Type： MT-S2108DI-C1
l Standards： IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
l Network Media (Cable)： 10Base-T: UTP category 3, 4, 5 cable (maximum 100m)，EIA/TIA-568 100ù STP (maximum 100m)，100Base-Tx: UTP category 5, 5e cable (maximum 100m)，EIA/TIA-568 100ù STP (maximum 100m)
l Number of Ports： 8 10/100Mbps Auto-Negotiation ports
l LED indicators： 10/100M Link/Act Othe Power
l Transfer Method： Store-and-Forward
l Switching Capacity： 1.6G
l MAC Address Learning： Automatically learning, automatically Update
l Frame Filtering and Forward Rate： 10Mbps: 14880pps, 100Mbps: 148800pps
l Dimensions (W×D×H)： 127×67×26（mm）
l Environment： Operating Temperature: 0 C~40 C (32 F~104 F)，
Storage Temperature: -40 C~70 C (-40 F~158 F)，
Operating Humidity: 10%~90% non-condensing，
Storage humidity: 5%~90% non-condensing
