| MODEL |
MJ-500 |
MJ-600 |
| Printing technology |
Dual head, 96 nozzle Piezo Inkjet |
| Max printing width |
210 to1107mm(8-5/16to43-9/16in) |
210 to1615mm(8-5/16to63-9/16in) |
| Acceptable Material Width |
210 to1117mm(8-5/16to44in) |
210 to1625mm(8-5/16to64in) |
| Conditions for usable materials |
Maximum material thickness: 0.039 in. (1.0 mm) (When head is raised)
Maximum diameter for roll material: 7-1/16 in. (180 mm)
Core inner diameter for roll material: 2 in. (50.8 mm) or 3 in. (76.2 mm)
Maximum weight for roll material: 44.1 lb. (20 kg) |
| Ink cartridges : Pigment |
Use only pigmented ink cartridges exclusively for use with the Hi-Fi JET. Capacity : 220 cc ±5 cc; Colors: The four colors black, cyan, magenta, and yellow or the eight colors black, cyan, magenta, yellow, orange, green, light cyan, and light magenta |
| Ink cartridges : Dye-based |
Use only dye ink cartridges exclusively for use with the Hi-Fi JET. Capacity : 220 cc ±5 cc; Colors: Cyan, magenta, yellow, and black |
| Printing Resolution |
1440 x 1440* dpi / 720 x 1440 dpi / 540 x 1080 dpi / 1080 x 1080 dpi / 720 x 720 dpi / 540 x 360 dpi |
| Print Margin |
Front edge: 2-13/16 in. (70 mm) , Rear edge: 4-1/4 in. (107 mm), Left and Right: 0 in. - 0.394 in. (0 mm-10 mm) variable, default: 0.394 in. (10 mm)
Margin between pages: 0 in. - 7-7/8 in.( 0 mm - 200 mm) variable, default: 0.394 in.(10 mm) |
| Distance accuracy |
Error of less than ±0.3% of distance traveled, or 0.3 mm, whichever is greater (on Roland PET-film, print travel: 39-3/8 in.(1 m)) |
| Printing heads cleaning |
Automatic cleaning and manual cleaning |
| Interface |
Bi-directional parallel interface (compliant with IEEE 1284: ECP mode) and Ethernet 10Base-T or 100Base-TX |
| Instruction system |
RD-RTL, RD-PJL |
| Power consumption |
Printing mode Maximum: 1.3A/100V-240V ±10% 50/60 Hz Standby mode Maximum: 0.5A/100V-240V ±10% 50/60 Hz |
| Acoustic noise level |
Printing mode 60dB (A) or less (According to ISO7779) Standby mode 40dB (A) or less (According to ISO7779) |
| Dimensions (With Stand) |
2246mm[W]*740mm[D]*1241mm[H]
(88-7/16in.[W]*29-3/16in.[D]*48-7/8in.[H]) |
2500mm[W]*740mm[D]*1241mm[H] (98-7/16in.[W]*29-3/16in.[D]*48-7/8in.[H]) |
| Weight (With Stand) |
257.9 lb. (117 kg) |
282.2 lb. (128 kg) |
| Environment |
Power on : Temperature: 59 to 89.6 oF(15 to 32 oC), Humidity: 35 to 80% (non-condensing)
Power off : Temperature: 41 to 104 oF( 5 to 40 oC), Humidity: 20 to 80% (non-condensing) |
| Included items |
Power cord,User’s Manual, Drain bottle, Roland ColorChoice software |
