On the basis of LW520F wheel loader, LW521F wheel loader gets improved in terms of hydraulic system, working mechanism, frame assembly and cab, by which greatly improving the machine performance in the aspects of machine technical data, reliability, operation comfort, working efficiency, machine maintenance and out-looking shape.
1. Rational and optimized designing of the machine frame improve the stability of the machine.
2. The hydraulic system is of integrated dual-pump system, which is featured in fuel-saving and high efficiency, and while reducing the total working cycling time, by which improving the working efficiency.
3. The gear-shifting control adopts flexible controlling mechanism, which features in high reliability and easy operation. The Reverse warning device makes it more safe and stable during working.
4. The more rational axle load distribution makes the machine has more competitive advantage in term of traction.
5. The critical articulated joint adopts anti-dust enclosed lubrication. So the pin shaft and pin sleeve have longer service life.
6. The out-looking shape is of streamline designing, with XCMG feature.
7. The canopy-cab, adopting “Korean Green” glass, is of unique out-looking shape and harmonious color matching.
8. The injection-moulded instrument panel is very nice in out-looking. The cab is tandardly equipped with heater.
9. The hood is of non-metal material, which features in noise-absorbing and easy maintenance.
10. The 3.0 m3 bucket is equipped on standard machines, fitted with cutting edge, which improves the machine reliability and endurability.
11. The power unit used on the machine is of WeiFang engine: WD61567G3-29
|
Items |
Unit |
Technical Data |
|
L/W/H |
mm |
7772/3000/3280 |
|
Rated loading weight |
t |
5 |
|
Operating weight |
t |
16.5 |
|
Max traction force |
kN |
140 |
|
Static side-dumping load |
kg |
10000 |
|
Min ground clearance |
mm |
450 |
|
Steering angle |
o |
35degree to both left and right |
|
Min turning radius |
|
5670 |
|
Speed |
|
|
|
Forward I gear |
km/h |
0-11 |
|
Forward II gear |
km/h |
0-36 |
|
Reverse speed |
km/h |
0-15 |
|
Hoisting height |
mm |
6000 |
|
Traction height |
mm |
1090 |
|
Engine model |
|
Shanghai Engine G6035G1b |
|
Rated power |
Kwr/min |
162/2200 |
|
Cylinder/cylinder dia./stroke |
mm |
6/135/150 |
|
Standard bucket capacity |
m3 |
3.0 |
|
Optional bucket capacity |
m3 |
3.5 |
|
Max break-out force |
KN |
145 |
|
Lifting capacity |
KN |
80 |
|
Total cycling time |
s |
12 |
|
Unloading height |
mm |
3110 |
|
Unloading distance |
mm |
1180 |
|
Optional attachment |
Clamp and side-dumping buckets |
|
Tyre specification |
|
23.5-25 |
|
Layer number |
|
16 |
