Higer Large Coach S90

Higer Large Coach S90

Higer Large Coach S90

  Prev Product Contact Now Next Product

Detailed Product Description

Model
Higer 6109
Engine
YC6G270-20(270hps,EUROII)   YC6G240-30(240hps,EUROIII)
YC6G270-30(270hps,EUROIII)  JO8C(285hps,EUROII)
C245 20(245hps,EUROII)       ISBE250 30(250hps,EUROIII)
Clutch
Diaphragm spring clutch(Φ430)/Hydraulic clutch　
Transmission
6-speed manual gearbox/ ZF 5HP502 Auto transmission
Suspension
Multileaf spring with front/rear stabilizer bar / air bellows suspension
Axle
Dongfeng 5.5T front axle and 11T rear axle
Steering
Power steering gearbox/ZF steering gearbox
Braking
Front /rear drum braker;dual circuit air braking system ;Parking brake acting on rear axle
Tyre
11R22.5 tubeless tyre
Others
Auto slack adjustor; ABS/WABCO ABS*; electric/integration retarder*; automatic chassis lubrication system*
BODY
A/C
Higer roof mounted dependent A/C(BOCK compressor,25.6KW) with ventilation, air filtrating function
Heater
Front windshield defroster, independent heater*
Seats
High backrest without adjustable function passenger seats , adjustable High backrest &full adjustable function driver seat
Door
Front pneumatic out-swing door;retractable step*
Windows
Sealed side windows( sliding driver and rear side windows ),two emergence exit
Lighting
Inner parallel ceiling light; reading lamps; step lamps; high position brake lamp
Electrical system
Battery:2×200Ah,Generator: 2*28V/150A ,audio system,video system with CRT/LCD* monitor, SIMENS VDR* ,Auto fire extinguisher*
Others
Powder coating partition ;aluminum alloy luggage cabin door;digital clock;DUPONT painting;
SPECIFICATION
Standard seat number
       41+1+1
Overall dimensions
(mm)
10490X2500X3590
Wheel base
5000
Front overhang
2160
Rear overhang
3160
Rated passenger
24~47
Max. Speed(Km/h)
120/105
Kerb Mass/GVW(kg)
11200/14900
Diesel tank(L)
400
Entry height(mm)
≤400
Central aisle height (mm)
2050
Remark options
