solar panel

Detailed Product Description

Model	Standard power (W)	Best working voltage (V)	Best operating current(A)	Open －circuit voltage(V)	Short-circuit current(A)		Dimension(mm)
HF004M-12/Db	4	16.8	0.24	21.0	0.30		21630625
HF005M-12/Db	5	16.8	0.30	21.4	0.33		21630625
HF006M-12/Db	6	16.8	0.36	21.4	0.39		21630625
HF008M-12/Fb	8	16.8	0.48	21.0	0.56		36030625
HF010M-12/Fb	10	16.8	0.60	21.4	0.68		36030625
HF012M-12/Fb	12	17.2	0.70	21.6	0.80		36030625
HF018M-12/Cb	18	16.8	1.07	21.0	1.21		65630625
HF020M-12/Cb	20	16.8	1.19	21.4	1.21		65630625
HF022M-12/Cb	22	17.6	1.25	21.8	1.30		65630625
HF038M-12/Eb	38	17.2	2.21	21.6	2.44		63054130
HF040M-12/Eb	40	17.2	2.33	21.6	2.50		63054130
HF042M-12/Eb	42	17.6	2.39	21.9	2.54		63054130
HF050M-12/Eb	50	17.3	2.9	21.5	3.2		81154130
HF075M-12/Bb	75	17.2	4.36	21.6	4.87		119554130
HF080M-12/Bb	80	17.2	4.65	21.6	5.00		119554130
HF085M-12/Bb	85	17.6	4.83	21.9	5.14		119554130
HF155M-24/Ac	155	34.4	4.51	43.2	4.90		158080835
HF160M-24/Ac	160	34.4	4.65	43.2	5.00		158080835
HF165M-24/Ac	165	34.8	4.74	43.6	5.04		158080835
HF170M-24/Ac	170	35.2	4.83	43.8	5.14		158080835
HF175M-24/Ac	175	35.2	4.95	44.2	5.20		158080835
HF180M-18/Ub	180	25.8	6.98	32.4	7.82		148299235
HF190M-18/Ub	190	26.2	7.25	32.8	8.00		148299235
HF200M-18/Ub	200	26.6	7.63	32.8	8.10		148299235
Insulation：≥100MW						Wind Bearing：≥120km/h
Voltage Standoff：AC2000V DC3000V						System Voltage：1000V
Impact Resistance： Hail Impact Test (225g steel ball drops drops from height of 100cm)

FOB Price:	USD2.50-2.75shanghai
Other Price Terms:	CIF, CNF
