AC adapter BA0651ZI-190-A01

Detailed Product Description

Description:

Input Condition	AC100～240V 50/60 Hz 1.5A Max
Input Rated Voltage	110Vac～240Vac
Input Voltage Range	100Vac～264Vac
Input Rated Frequency	50/60Hz
Input Frequency Range	47Hz～63Hz
Input Current	1.5A Max
Input Inrush Current	50A Max
Input No Load Power Consumption	0.5W Max At 115Vac/230Vac
Efficiency	85% Min
Rated Output Voltage & Current	19V/3.42A
Output Line Regulation	±1%
Output Load Regulation	±5%
Output Over Shoot	10% Max
Output Ripple And Noise	1% Max
Output Rising Time	20ms Max At 115Vac
Output Hold up Time	8 ms Min At 230Vac
Protection	OCP OVP SCP OPP OTP
Dielectric Withstand Voltage	3KV 5mA 60s
Leakage Current	0.25 mA At 230Vac
DC Plug Specification	Could Be Changed（See The Picture）
Dimension	45×107×31 mm
Operating Temperature Range	0℃～40℃
Storage Temperature Range	-20℃～+85℃
