170degree wide view angle Vehicle Rear View Camera,OV-7950 CMD from USA,fix len from Korea

Model No.:TOP-291M

Features:

◆OV-7950 CMD from USA,Super High effect

◆Wide view angle:170°

◆fix len from Korea,anti-high temperature

◆waterproof(IP67~68),anti-theft

◆high aluminum alloy

◆with reversing reference line

◆with IR Effect

Specifitions:

• 1.)Sensor: OV-7950 CMD,Super High Denifition
• 2.)Horizontal resolution:420TV lines
• 3.)Number of Pixels: NTSC:512(H)*492(V)
• 4.)Wide View Angle: 170°
• 5.)Len: 2.1mm
• 6.)Reversing reference line: optional
• 7.)Waterproof Resistance:IP67~68
• 8.)Auto Gain Control: Auto
• 9.)Usable Illumination: 0.1 Lux(F:1.2)
• 10.)Video Output: 1.0Vp-p 75Ω , Negative
• 11.)Electronic Shutter Time: Auto:NTSC 1/60-1/100,000Sec
• 12.)Operation Temperature: -20℃- +80℃ RH 95% Max
• 13.)Storage Temperature: -40℃- +100℃ RH 95% Max
• 14.)Gamma Characteristic: 0.45
• 15.)White Balance: Auto
• 16.)Scanning System: NTSC 525 Lines, 60Field/Sec
• 17.)Sync System: Internal Synchronization
• 18.)Power Supply: DC12V±10%,40 mA
• 19.)high aluminum alloy

Accessories:5m video cable,1.5m power cable,user manual
