ATV(XY-ATV50EC)

Prev Product

Next Product

Detailed Product Description

XY-ATV50EC

Specification:
ISO9001:2000,VIN,EEC No.:e13*2002/24*0084*01
1>Dimension:(L*W*H): 1,230*730*850
2>Wheel base (mm): 830
3>Ground clearance (mm): 70
4>Max speed (km/h):>40
5>Max load:237.8kgs
6>Brake method(F/R):Double Drum / Disc
7>Tire size(F/R):145/70-6 / 145/70-6
8>Seat height(mm):620.
9>Fuel capacity:3.5L
Engine type: 50cc,4-stroke, air-cooled, 1 cylinder,
1>BoreXStroke:39X41.4
2>Cylinder capacity:49cm3
3>Compression ratio:8.8:1
4>Max. power and speed:2.4/6000(kw/min-1)
5>Max. torque:4.4/4000(n.m/min-1)
6>Starting method:electric
7>Transmission:4-speed,Auto clutch,chain,420H
Carton dimensions:1,160*690*660mm
Conveyance:48pcs/20' ; 136pcs/40'HQ
COLOUR:blue, red,black,yellow,green
48PCS/20
135PCS/40HQ

Post Date:	9/14/2008
Expiry Date:	9/9/2009
