We can provide 1-12 layer pcb printed circuit boards. In addition, we can provide pcb assembly . Please kindly give us your files for a quote. We can deal with CAM350,PCAD2002,PROTEL,Power PCB and PADS. The parameter of pcb we can produce as follows:
1)material: FR-4, FR-1, CEM-1, CEM-3, FR-4 Halogen Free
2)layer: 1-12
3)board thickness: 0.4mm-3.2mm
4)copper thickness: 0.5oz, 1.0oz, 2oz, 3oz,
5)min.drilled hole size: 0.2mm
6)min.track width/space: 4/4mil(0.1/0.1mm)
7)surface finish: HASL, Lead free HASL, OSP, Gold-plating, Chemical silver, Chemical gold(ENIG), Chemical tin, Carbon ink,
8)solder mask color: green, yellow, black, white, red, blue
9)profiling: Punching, Routing, V-cut, Golden finger, Beveling
10)V-cut angle: 20°，25°，30°，45°，
11)Beveling angle: 20°，25°，30°，45°
12)Max working panel: 24*20 (610mm*508mm)
13)E-test voltage: 50-300V
14)Certificate：UL, ISO9001, ISO14001, ISO/TS 16949, RoHS
15)Impedance control:
Microstrip impedance: 50-60Ω，Tolerance: ±10%
Differential Impedance: 90-120Ω, Tolerance: ±10%
16)Quality standard: IPC-A-600F
