water pump

Operating conditions
*Liquid temperature up to 60
*Ambient temperature up to 40
*Total suction lift up to 9mt.
*Continuous duty

Motor
*Two-pole induction motor(n=2850r.p.m)
*Insulation Class B
*Protection IP44

Material
*Pump body: Cast iron
*Motor support: Cast iron
*Motor housing: Aluminum
*Impeller: Brass
*Shaft with rotor: 45# Steel,AISI 416 stainless steel if request
*Mechanical seal: Carbon/Ceramic
Single phase 220V-240V/50Hz
Single phase 110V-127V/60Hz if request
Single/three phase 220V/60Hz if request
