three phase motor

 Y2 series three-phase induction motor is specially designed for European market, whose terminal box is located on the top. This motor has a very compact structure and attractive appearance. The sizes and mounting dimensions are produced according to the IEC standard. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.
We can also supply aluminum housing type for frame size below IEC132.
Y2 series motors can be widely used as driving equipments of various machineries, such as, machine tools, blowers, pumps, compressors, transporters, agricultural and food processing.
Specifications & Features
Rated voltage: 380V or on request, Rated frequency: 50Hz or 60Hz
Connection: Star-connection for 3KW or less while delta-connection for 4KW or more.
Duty/Rating: Continuous (S1).
Insulation class: F, the temperature rise of the stator winding is examined at 80K (by resistance method).
Protection class: The main body of the motor is IP54, terminal box reaches IP55
Cooling method: ICO141 (cooled by SELF-FAN)
Improving electromagnetic and construction design, low noise and little vibration.
Operating Conditions
Ambient temperature: -15≤θ≤40
Altitude: not exceeding 1000meters above sea level.
Relative humidity less than 90% .
Available type
Frame H63 to 315, 2/4/6/8 poles, Rated output: 0.12KW-200KW
B3/B5/B14/B35/B34 mounting; Mounting dimensions according to IEC60034 standard
