Detailed Product Description

u High-density and programmable communication media processor, SOC single chip solution, equipped with two processors, ARM9 and DSP.

u Support both high sensitivity CCD and other CMOS sensor.

u Support day and night function with infrared. (Refer to the model)

u Support Optical Zoom and auto-focus function. (Refer to the model).

u H.264 baseline profile@ Level 2.2, easily to realize transmission of High Definition video over low network bandwidth.

u Support SD Card Storage, the biggest storage capacity 4G. (Refer to the model).

u Support UPNP and DDNS.

u Built-in Web Server enables the use of a standard Web browser for viewing and management.

u Support IEEE802.11b/g.

u Support CDMA1X and GPRS mobile network and surveillance via the mobile phone.

u Support dynamic IP address, LAN, Internet (ADSL and Cable Modem)

u Support Network protocols：HTTP, TCP/IP, UDP, SMTP, DDNS, DNS, SNTP，BOOTP, DHCP, FTP,SNMP.

u Support Bi-directional real- time transmission of audio talk-back &broadcast.

u Network self-adapting technology to adjust video frame rate utomatically according to the network bandwidth.

u Provide motion detection (Area &Sensitivity can be set) and E-mail alarm functions.

u Provide RS485/RS232 serial port with several built-in high-speed domes and decoder protocols supports transparent protocols.

u Auto-recovery function if some abnormity occurs and auto-connection if the internet interrupts.

Image Sensor	CCD	Support Sony/Sharp interlace CCD sensor
	CMOS	Line-Scanning CMOS sensor
Video Compression	H.264 baseline profile@Level 2.2
Video Resolution	CCD(tiptop) D1（704x576 PAL，704x480 NTSC） CMOS (tiptop) VGA（640x480）,Line-Scanning.
Adjustment of Video Parameter	Brightness, Contrast, Saturation, Hue and Image Quality.
Streaming Format	Pure Video Streaming or Audio Composite Streaming
Video Frame Rate	CCD:1 – 25 frames/second（PAL）/ 1 – 30 frames/second（NTSC） CMOS: 1 – 25 frames/second (Set optional)
Video Compression Bit Rate	10Kbit/S～4Mbit/S
Audio Input	1 Channel Linearity Input or no original Microphone input, Microphone Resistance: 2.2ＫΩ.
Audio Compression	G.726
Audio output	1 Channel Linearity output
System Interface	10Base-T/100Base-TX Ethernet Network Interface RS485 Interface (control the pan decoding) SD Card Interface
WiFi	Support IEEE802.11b/g
IR Distance	Refer to model: Respectively 10M,20M,30M,50M
Lens Parameter	Refer to model: support Optical Zoom and Auto-Focus function
Alarm Input	1 Channel on/off input.
Alarm Output	2 Channel on/off output, 120VAC 1A/24VDC
Power Input	DC 12V 1A
Maximum Power	CCD: Less than 4.5W; CMOS: less than 3W
Operating emperature	-10℃ ~ +55℃
Operating Humidity	10% ~ 85%
Storage Temperature	-20℃ ~ +70℃
