SPECIFICATION
GENERAL
LENGTH x WIDTH x HEIGHT
PAY LOAD
20 Feet container trailer suit for 1 x 20ft container
40 Feet container trailer suit for 2 x 20ft, 1 x 40ft or 1 x 45ft container
30 - 60 tons
RUNNING GEAR
SUSPENSION
DRUMS
HUBS
WHEELS
TIRES
AXLES
BRAKES
ABS SYSTEM
VALVE
BRAKE CHAMBER
Air suspension or Mechanical (multi leaf spring) Suspension with equalizer beam
Outboard mounted, hub piloted cast steel
Cast steel 8 or 10 studs, oil seals
Steel disc, prepainted white
Nylon, radial or tubeless tires, famous brand, include 1 spare tire
2, 3 or 4 axle, BPW, SAF, FUWA, LT or ANQIAO brand, 12 – 20 tons payload per axle
Dual line brake system, non-asbestos, includes automatic slack adjusters
Available upon request
WABCO or SEALAND emergency relay valve
TGL or FUWA 30/30 chamber, air-actuated
UNDERFRAME
MAIN BEAM
CROSS BEAM
PLATFORM
TWIST LOCKS
KING PIN
LANDING GEAR
MUD FLAPS
BUMPER
APPENDIX
I shape, Mild Alloy (Q345B, tensile strength 34.5kg/mm^2) by Automatic submerged arc welding.
U shape, Mild Alloy Q345B, tensile strength 34.5kg/m^2 3mm thickness checkered sheet as floor.
U-profile beams with reasonable interval as supporting beam, longitudinal cross member made of
U channel. Width of platform is suitable for standard container.
Side pillars are available upon request.4, 8 or 12 locking pins design,
center lock pin can laid down JOST or FUWA brand, 2", 2.5" or 3.5"welded or bolted in type JOST,
FUWA, Baohua Holland brand, Static capacity 25 Tons
Anti-sail, mounted on sliding tandem
Heavy duty bumper at the end
1 toolbox
2 Spare tyre carriers
ELECTRICAL & PAINT
LIGHTS, REFLECTORS
WIRING
AIR/ELEC. CONNECTOR
PAINT
Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light 24V, 6 lines
ISO standard air connector,
24V 7-pin plug socket
Sand blasting before painting
1 coat of anticorrosive primer
2 coats of finish urethane paint
