Model: LLA306
Layer x step: 3 x 6
Extension length: 4060mm
Folding size: 1740x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 9.52kg/9.67kg
Quantity/container: 265pcs/20’FT; 530pcs/40’FT; 590pcs/40’HQ
Model: LLA307
Layer x step: 3 x 7
Extension length: 4350mm
Folding size: 2030x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 10.7kg/11.95kg
Quantity/container: 220pcs/20’FT; 440pcs/40’FT; 480pcs/40’HQ
Model: LLA308
Layer x step: 3 x 8
Extension length: 5800mm
Folding size: 2320x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 12.08kg/12.23kg
Quantity/container: 200pcs/20’FT; 400pcs/40’FT; 440pcs/40’HQ
Model: LLA309
Layer x step: 3 x 9
Extension length: 6670mm
Folding size: 2610x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 13.36kg/13.52kg
Quantity/container: 160pcs/20’FT; 320pcs/40’FT; 360pcs/40’HQ
Model: LLA310
Layer x step: 3 x 10
Extension length: 7540mm
Folding size: 2900x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 14.65kg/14.81kg
Quantity/container: 160pcs/20’FT; 320pcs/40’FT; 360pcs/40’HQ
Model: LLA311
Layer x step: 3 x 11
Extension length: 7860mm
Folding size: 3190x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 15.83kg/16.09kg
Quantity/container: 90pcs/20’FT; 240pcs/40’FT; 270pcs/40’HQ
Model: LLA312
Layer x step: 3 x 12
Extension length: 9280mm
Folding size: 3480x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 17.2kg/17.36kg
Quantity/container: 90pcs/20’FT; 240pcs/40’FT; 270pcs/40’HQ
Model: LLA313
Layer x step: 3 x 13
Extension length: 10.5M
Folding size: 3770x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 18.5kg/18.67kg
Quantity/container: 80pcs/20’FT; 240pcs/40’FT; 270pcs/40’HQ
Model: LLA314
Layer x step: 3 x 14
Extension length: 11.2M
Folding size: 4060x460x160mm
Space between two rungs: 290mm
Aluminum mode: 6063 thickness: 1.2mm
Max load: 150kg
N.W/G.W: 19.8kg/19.97kg
Quantity/container: 80pcs/20’FT; 180pcs/40’FT; 230pcs/40’HQ
