Acid-resistant Brick and Plate

Detailed Product Description

Acid-resistant brick

Common ceramic bricks and plates are widely in metallurgy industry, chemical industry, and petrifaction industry as liners in reaction furnaces, drying towers, baths, floors and channels where corrosion resistances is needed.

Physical features of acid-resistant brick

Specific gravity	Water absorption	Bending strength	Urgent cold and heat resistance	Strength
2300-2400kg/m³	＜1%	＜39.2MPa	20-200℃	Mohs8-grade

Chemical features of acid-resistant brick

SiO₂	Al₂O₃	K₂O	Na₂O	CaO	MgO	Fe₂O	Acid resistance
69.8	22.5	2.7	0.95	0.82	0.12	0.49	99.8%

Specifications and type

Name	Size	Name	Size
Standard brick	230×113×65	Acid-resistant ceramic plate	180×110×15-30
Rectangle-brick	230×65×65	Acid-resistant ceramic plate	150×150×15-30
Horizontal wedge brick	230×113×55/65	Acid-resistant ceramic plate	150×70×15-30
Horizontal wedge brick	230×113×25×65	Acid-resistant ceramic plate	100×100×10
Verical wedge brick	230×113×55/65	Acid-resistant ceramic plate	80×80×10
Verical wedge brick	230×113×25×65	Acid-resistant ceramic plate	50×50×10

Notes: 1. One side trough, glazed and non-glazed types of acid-resistant ceramic plates.
2. Any size and shape of brick can be customized to meet users’ requirement.
