KC-S-3040F Flat screen printing machine

Detailed Product Description

Specifications	1.Maximum printing thickness: 300 MM 2.Air consumption: 80 Liter/Min 3.The diameter of maximum printing workpiece: Φ125MM 4.The arc of maximum printing workpiece: 380MM 5.The maximum printing speed: 1300Pic/HR 6.Weight: 187kg. 7.Max Frame dimension: 550×400mm; 8.Maximum Plain printing area:300×400mm; 9.Max diameter of workpiece: Φ150MM.
Advantages	1.Fully automatic control by microcomputer & easy handling 2.Four figures automatic counter 3.Automaticoil scrabbing, oil return and lifting table 4.Adujustability of routs and speeds 5.Self-poise scraper to balance printing pressure 6..High precision and easy & quick adjustability
