XiangSheng Music Curve D-2020-KT88 integrated Tube Amplifier

Product Description:

The plane, which was based on the improvement of the third generation Danji, elegant formal appearance modeling, grade skills.

Classic parallel push-pull circuit equipped with the famous Shuguang KT88 tubes, this thing produces nothing but beautiful, gorgeous music.It is fit for listening to all kind of music.

You don't see too many of these listed anywhere either and this is because it is cherished very much in the audiophile world. It is a highly recommended and desirable tube amplifier with the reputation of sounding.

◆ Chassis is made of stainless steel of 1.2mm in thickness with wire brushing.
◆ Big metal knob, comb-like feet for reducing shaking.
◆ High-grade RCA terminal with gold plating.
◆ 4Ω and 8Ω power output terminals with gold plating.
◆ Side panels made from cherry wood.
◆ Blue power indicator.

Parameter:

Input Impedance:     100Kohm
Output Impedance:   4ohm    8ohm
Input Sensitivity:        500--2000mV
Total Hamonic  Distortion:   ≤1%(1KHz)
Frequeney responses:    20Hz-30KHz±1dB
Maximum output:       40W×2(8ohm   Standard)  30W×2(8ohm   Triode)
Signal to Noise Ratio:   89dB
Input Jacks:      4 group
Output Jacks     2 group
Supply  Votage:     AC110- AC220V availble 60Hz/50Hz
Size:      435mm(Width)×180mm(Height )×340mm(Depth)
Weight:  22kg
