Fast in straightening and cutting: our machine adopts German technology and could reach a highest straightening and cutting speed of 110m/m, 3 times that of domestic similar products.
Accurate measurement : the main character of our product is accurate measurement , with error less than or equal <=±1mm.
Model: CT-0.3-1
Wire Dia: 0.3-1mm
Length: 300-600mm
Speed: 54-108m/min
Dimensions: 1000x500x700mm
Weight: 1000kg
Model: CT-1.6-6
Steel Dia: 1.6-6mm,
Cutting Length: 600-5000mm,
Speed: 110 m/min
Dimensions: 7750x600x1260mm
Weight: 1000 kg
Model: CT-3-8
Steel Dia: 3-8mm,
Cutting Length: 100-6000mm,
Speed: 40 m/min
Dimensions: 7250X550X1150 mm
Weight: 700 kg
Model: CT-5-12T
Steel Dia: 5-12mm,
Cutting Length: 1000-12000mm,
Speed: 120 m/min
Dimensions: 18000x5000x2000mm
Weight: 5000 kg
Model: CT-6-14
Steel Dia: 6-14mm,
Cutting Length: 3000-12000mm,
Speed: 120 m/min
Dimensions: 14000x500x1260mm
Weight: 3500 kg
Model: CT-8-16T
Steel Dia: 8-16mm,
Cutting Length: 1000-12000mm,
Speed: 180 m/min
Dimensions: 18000x5000x2000mm
Weight: 7000 kg
