Microwave PIR Detector with microstrip Resonator

Detailed Product Description

KH0766T microwave PIR detector, It adopts microwave and infrared detect, then deal with advance algorithm through computer chips, alarm exactly for the move of human. It is the most advanced in security field

Main functions:

Doppler microwave and the human body infrared double detector
Use advanced algorithms microprocessing technology
The real function of temperature compensation
Optional function pulse count
Strong anti-interference

Specifications:

Power: DC9-12V
Current: 25mA (power is DC12V)
Microwave equipment:
- Resonator: microstrip, DRO constant frequency
- Working frequency: 10.525GHz
- Detection distance: >15m
- Sense LED: green indicator light when microwave detect human moving
Passive PIR
- Sense LED : yellow indicator light when microwave detect human moving
- Sensor sensitivity: 1 to 2 pulse count can be chosen
- Detection angle: 110°
- Coverage area: 12 x 12m
- Temperature compensation: auto-temperature compensation
Alarm and anti-remove
- Alarm port (ALARM) : generally, it is closed, it cuts 2-3second when alarm, point capacity is 100mA/30V DC
Environmental conditions and other parameters:
- Working temperature: 10 to 55°C
- Conservation temperature: 25 to 65°C
- Electronics magnetic in EMI: >30V/m
- Anti-white light disturbance: >6,500 lux
- Size: 127.3 x 64 x 41 mm
