Strong Technology Shares ( HK) Limited

Outdoor full-colour display

Detailed Product Description


Technical Specification:
Color
Size
Bright
Wavelength
Test Condition
Red
346
450mcd
625±5nm
25℃,20mA
Green
346
1950mcd
525±5nm
25℃,20mA
Blue
346
350mcd
465±5nm
25℃,20mA
To get best white balance, color ratio is designed to be R:G:B=3:6:1




Module
Pixel Pitch:10mm
Pixel Density:10000pixel/㎡
LED Arrangement:1R1G1B
Drive Mode:Constant Current Driver
Scan Mode:1/4 Static scan
Module Resolution:16*8
Module Size:160mm*80mm


Cabinet
Cabinet Width:960mm
Cabinet Length:640mm
Cabinet Area:0.6144㎡
Cabinet Resolution:96*64



Display
Viewing Distance:10~~200m
Brightness:≥5000
Horizontal Viewing Angle:110°
Vertical Viewing Angle:70°
Working Temperature:-20℃~~ +50℃
Humidity:20%~~95%RH

Power
Power Voltage:5V
Max Power Consumption:≤1000W/㎡
Average Power Consumption:≤300W/㎡






System
Brightness Adjustment:Manual, 256 levels; Auto, 8 levels
Grey Grade:256 grade
Display Color:16.7M
Refresh Frequency:≥480HZ
Waterproof:IP65
Input:S-Video、RGB、RGBHV、YUV、COMPOSITION
MTBF:≥1000小时
Using Lifespan:50,000 hours
Miscellaneous Point Ration:≤0.0002
Communication Distance:100m with UTP cable
Assembly
Quick assembling structure makes it convenient to install and uninstall rapidly without any traditional manual tools.

Protection
Dustproof, humidityproof, lightningproof, staticproof etc.
Overcurrentproof, shortcurrentproof, overloadproof and shortloadproof.
FOB Price:USD2000-5000Shenzhen
