outdoor led display screen P18

Detailed Product Description

Product Description
Color   Size    Bright     Wavelength      Test condition
Red     546   450mcd    620-630nm        20mA
Green  546  1950mcd   520-530nm        20mA
Blue     546   350mcd    460-470nm       20mA
To get best white balance, color ratio is designed to be R:G:B=3:6:1

Module
Pixel Pitch:18mm
Pixel Density:3807(real)
LED Arrangement:2R1G1B(real)
Drive Mode:Constant Current Driver
Scan Mode:Static scan
Module Resolution:16*8
Module Size:288mm*144mm

Cabinet
Cabinet Width:1152mm
Cabinet Length:864mm
Cabinet Area:0.995
Cabinet Resolution:64*48

Display
Viewing Distance:18~~320m
Brightness:>5000
Horizontal Viewing Angle:110 degree
Vertical Viewing Angle:70 degree
Working Temperature:-20centidegree+50 centidegree
Humidity:20%~~95%RH

Power
Power Voltage:5V
Max Power Consumption:<900W
Average Power Consumption:<320W

system
Brightness Adjustment:Manual,256 levels;
Grey Grade:256 grade
Display Color:16.7M
Refresh Frequency:>480HZ
Waterproof:IP65
Input:S-Video\RGB\RGBHV\YUV\COMPOSITION
MTBF:>1000 hours
Using Lifespan:50,000 hours
Miscellaneous Point Ration:<0.0002
Communication Distance:100m with UTP cable

Assembly :Quick assembling structure makes it convenient to install and uninstall rapidly without any traditional manual tools.

Protection: Dustproof, humidityproof, lightningproof, staticproof etc.
Overcurrentproof, shortcurrentproof, overloadproof and shortloadproof.

Payment Details:
Payment Terms: Telegraphic Transfer (TT, T/T)
Minimum Order: 1 to 99 Square Meter




Other Price Terms:T/T
