Barbed Wire
Wire to be made into barbed wire is usually galvanized (coated with zinc) to protect it from corrosion. The wire must be perfectly clean and dry to be properly galvanized. First it is cleaned in a bath of hot, dilute hydrochloric acid, then rinsed with hot water. It then passes through a solution of hot zinc chloride or ammonium chloride to prevent rust from forming as it is dried. After drying, the wire passes through a bath of molten zinc. Excess zinc is wiped off and the coated wire is allowed to cool. (Some-times the wire is coated with aluminum instead in a similar way.) Wire can also be coated with zinc by a process known as electrogalvanizing. The wire is given a negative electric charge and passed through a solution of zinc sulfate or some other zinc salt. The positive zinc ions are attracted to the negative wire and form a coating.
Specifications of Barbed Wire
Gauge ofStrand and Barb in B.W.G.
Approximate Length per kilogram in Meter
Barbs Spacing 3"
Barbs Spacing 4"
Barbs Spacing 5"
Barbs Spacing 6"
12x12
6.0617
6.7590
7.2700
7.6376
12x14
7.3335
7.9051
8.3015
8.5741
12-1/2x12-1/2
6.9223
7.7190
8.3022
8.7221
12-1/2x14
8.1096
8.814
9.2242
9.5620
13x13
7.9808
8.899
9.5721
10.0553
13x14
8.8448
9.6899
10.2923
10.7146
13-1/2x14
9.6079
10.6134
11.4705
11.8553
14x14
10.4569
11.6590
12.5423
13.1752
14-1/2x14-1/2
11.9875
13.3671
14.3781
15.1034
15x15
13.8927
15.4942
16.6666
17.5070
15-1/2x15-1/2
15.3491
17.1144
18.4060
19.3386
