Brief introduction:
Bilang model 130 rice and wheat combine harvester is developed by adopting advantages of domestic full feed combine harvesters. It is convenient in operation. The cutting width is 1.36m.
Features
1-One lever control system can handle both turning of machine and lifting of cutter bar.
2-Double shaking sieves ensure more cleanness.
3-HST is available.
4-Light weight and strong power enable flexible movements in bad wet field condition.
Specifications:
1- Model: 4LZ-1.2 (model 130).
2- Harvesting capacity: 0.16-0.41ha./h.
3- Overall dimensions(length*width*height):4400*1700*2700
4- Weight: 1,880kg.
5- Engine: 490, 45hp/2400rpm
6- Chassis:
a) Rubber truck(width*pitch):350mm*90mm
b) Quantity of teeth: 44
c) Gearbox: special used for combine
d) Transmission: 6-forward,2-backward. HST(optional)
e) Ground pressure: 21kpa
f) Minimum ground clearance: 250mm
7- harvester:
a) Cutting width: 1360mm or 1600mm
b) Type of lifting: hydraulic lift
c) Conveyor: chain rack tooth type
d) Cylinder: axial flow, spike tooth type
e) Cleaning: plate sieve + fan( front blowing and rear suction) + double shaking sieves
f) Grain tank: 0.8CBM
8- technology index
a) total loss: below 3% for rice / 1.5%for wheat
b) breakage: below 2%
c) impurity: below 2%
