Project Machinery-FT-100G

Model: FT-100G
Frequency (vpm): 7000
Centrifugal force(KN): 19.8
Compaction depth(cm/in) :30（12）
Travel speed (cm/s,in/s): 48（18）
Efficiency (m²/hr,ft²/hr): 770（8300）
Plate size (mm): 460x610
Engine Model: XY168FB
Type: Forced air-cooled,4-stroke,OHV
Displacement(cc): 196
Max.Output(Hp/rpm): 6.5/3600
Fuel: Unleaded Gasoline
Fuel Tank capacity(L) : 3.6
Continuous Operating Hours(H): 3
Oil: SAE 10W30(Above CC grade)
Oil capacity(L): 0.6
Ignition System : T.C.I
Starting System :Recoil
Net Dimension LXWXH(mm): 1100x460x660
N.W./G.W.(kg): 93/113
