electric scooter(2)

Detailed Product Description

Spareparts and equipments

Tungsten alloy aluminium wheel

Brushless magnetoresistive motor

Aluminium wheel in rear and front

Controller with 9 cables

Straight disk brake(we also can supply rocker arm drum brake)

Voltage changer

Circuit breaker

16*3.0 puncture resistant K-shield

Vacuum tyre of Kenda / Zhengxin Brand

Luxurious rear view mirror

Guard rail/ bumper

Tail box

Baking finish: Friction for three times and spraying for six times,
Plasma techniques, coating varnish, evironment friendly

Relative technical performance of electric bike

Net weight                         ≤38kg

Load weight                       100 kg

Rated speed                     18- 30km/h

Max range                         60~100km

Battery
Type                                    lead-acid battery

Specification(capacity)          10Ah 12AH

Standard voltage                  36V

Motor
Model                                  brushless

Rated power                         180-350W

Rated speed of revolution      180~390 r/min

Rated voltage                       36V

Rated torque output              6.25~10.5 N. M

Charger
Under voltage protection index           31.5+/-0.5V
Controller
Current limiting protection                15+/-1A/

This electric scooter has very good performance .
