| Model No.: SB100 |
| Features: |
| 1. Wall material EPS foam plate. Rockwool, XPS materials available too, good for temperature keeping. |
| 2. Outside size (mm): (L) 7050 x (W) 5250 x (H) 3600 |
| 3. Inner size (mm): (L) 6900 x (W) 3900 x (H) 2750 |
| 4. Entrance dimensions (mm): (W) 3000 x (H) 2700 |
| 5. Working door (mm): (W) 800 x (H) 2000 |
| 6. Intake air flow 25000 m3/h & exhaust air flow 14000 m3/h |
| 7. Intake air: centrifugal fan; exhaust air: axle flow fan |
| 8. Air Velocity: 0.3 (m/s) |
| 9. Working temperature: 60 ~ 80 ℃ |
| 10. Fuel oil consumption: 4 ~ 5 (kg/h) |
| 11. Total power: 11KW |
| 12. Noise level: < 80dB |
| 13. Burner 140000 Kcal |
|
|
|
| Model No.: SB200 |
| Features: |
| 1. Wall material EPS foam plate. Rockwool, XPS materials available too, good for temperature keeping. |
| 2. Outside size (mm): (L) 7050 x (W) 5250 x (H) 3600 |
| 3. Inner size (mm): (L) 6900 x (W) 3900 x (H) 2750 |
| 4. Entrance dimensions (mm): (W) 3000 x (H) 2700 |
| 5. Intake air flow 36000 m3/h & exhaust air flow 14000 m3/h |
| 6. Air Velocity: 0.36 (m/s) |
| 7. Work Temperature: 60 ~ 80 ℃ |
| 8. Fuel oil consumption: 4 ~ 5 (kg/h) |
| 9. Total power: 14KW |
| 10. Noise level: < 80dB |
| 11. Burner 200000 KCal optional |
|
|
|
| Model No.: SB300 |
| Features: |
| 1. Wall material EPS foam plate. Rockwool, XPS material available too, good for temperature keeping. |
| 2. Outside size (mm): (L) 8700 x (W) 5850 x (H) 4300 |
| 3. Inner size (mm): (L) 8600 x (W) 4000 x (H) 3500 |
| 4. Entrance dimensions (mm): (W) 3100 x (H) 3500 |
| 5. Air flow capacity: 36000 (m3 /h) |
| 6. Air Velocity: 0.3 (m/s) |
| 7. Work Temperature: 60 ~ 80 ℃ |
| 8. Fuel oil consumption: 7 ~ 9 (kg/h) |
| 9. Total power: 13KW |
| 10. Noise level: < 80dB |
| 11. Burner 260000 KCal optional |
|
|
|
| Model No.: SB500 |
| Features: |
| 1. Wall material EPS foam plate. Rockwool, XPS material available too, good for temperature keeping. |
| 2. Outside size (mm): (L) 15150 x (W) 6900 x (H) 5400 |
| 3. Inner size (mm): (L) 15000 x (W) 5000 x (H) 4800 |
| 4. Entrance dimensions (mm): (W) 4000 x (H) 4800 |
| 5. Air flow capacity: 80000 (m3 /h) |
| 6. Air Velocity: 0.3 (m/s) |
| 7. Work Temperature: 60 ~ 80 ℃ |
| 8. Fuel oil consumption: 25 ~ 30 (kg/h) |
| 9. Power: 30KW |
| 10. Noise level: < 120dB |
| 11. Burner 260000 Kcal |
|
