Overall dimension: |
|
Length: 11230 mm |
|
Width : 4130 mm |
|
Height : 4780 mm |
|
|
|
Loading capacity : |
|
The 1st row : Load center: 1965mm |
|
The 1st row : Floor 1-4: 45000 kg |
|
The 1st row : Floor 5: 43000 kg |
|
The 2nd row : Load center: 3815mm |
|
The 2nd row : Floor 1-4: 31000 kg |
|
The 3rd row : Load center: 6315mm |
|
The 3rd row : Floor 1-3: 15000 kg |
|
|
|
Engine : |
|
Model : VOLVO TWD1240VE |
|
Type : In-line 6 cylinders, 4 strokes, central water cooled, turbo charged, electro-injection |
|
Control mode : EDC III full electric control system of CAN trunk |
|
Rated power : 256 kW/2100 r/min |
|
Rated torque : 1751 Nm/1200 r/min |
|
Tail gas discharge standard : Euro II |
|
Average oil consumption ratio : 197 g/kW.h |
|
|
|
Gear shifting box : |
|
Model : CLARK 15.5HR36432 |
|
Gearing mode : Automatic/manual |
|
Gears : 4 gears for front and rear respectively |
|
|
|
Driving axle : |
|
Mode : KESSLER+CO D102 PL341 |
|
Traveling brake : Multi-sheet wet brake |
|
Parking brake : Disk type brake of spring brake and hydraulic release |
|
Max. static axle load : 1500 kN |
|
|
|
Lifting tool : |
|
Model : ELME817 |
|
Rotary angle : +105 /-195 |
|
Side movement distance : +800/-800 mm |
|
Max. load-bearing : 45000 kg |
|
Available scope : ISC 20’-40’ |
|
Lifting object : Container |
|
Overall mass : 69500 kg |
|
|
|
Arm : |
|
Max. hoisting height : 15100 mm |
|
Obliquity :0-60 |
|
Travel :7070mm |
|
Max. hoisting speed (non-load/full load) : 420/250 mm/s |
|
Max. traveling speed (non-load/full load) : 25/21 km/h |
|
Max. approaching speed (non-load/full load) : 360/360 mm/s |
|
Grade ability (non-load/full load) : 39/32 % |
|
Max. tractive force : 360 kN |
|
Min. turning radius : 8000 mm |
|
Steering mode : Servo-aid turning |
|
Wheel base : 6000 mm |
|
Min. clearance : 350 mm |
|
Traveling speed : |
|
1st gear : 3.6 km/h |
|
2nd gear : 8.6 km/h |
|
3rd gear : 14.8 km/h |
|
4th gear : 25 km/h |
|
Noisy level at cab : ≤72 dB |
|
Temperature of cab : 15-25degree |
|
Lubrication mode : Concentrated lubrication |
|
Working pressure of hydraulic system : 23 MPa |
|
Total discharge capacity of hydraulic system: 240 ml/r |
