ISO9001:2000; CE & SONCAP certificate
Silent Gensets produced by POWERTEC not only meet with the sound control requirement of China Environment Protection Bureau, but also ensure cooling aeration request by normal operation. All the Silent Gensets could be intalled in the open air to save space. POWERTEC Silent Gensets are modularize designed, compact constructer and easy to install and move. The high-tech design ensures each detail data exact and durable use.
Adopt asembly instruction which is facilitate to maintain.
Special high-temperature flame-retardant sound insulation sponge
Slap-up hinge and door handle.
Noise Level: 85DBA within 1M; 75DBA within 7m
Standard Genset Features:
Cummins water cooled diesel engine,
Oil and fuel filter fitted, water separator
Lube-oil drain valve fitted
Electric starter & Charge altimeter 24v DC
Electronic governor
Normal duty air filter
Single bearing alternator, class H /IP21
Standard voltage 400/230 volts, 50Hz
Exciter/Voltage reg-Torque Match as standard
SmartgenHGM6310 with Bargraph as standard
3-circuit breaker
Welding steel base with vibration block base
Silencer
Starting storage battery
Green body, black base
Contract plastic film for package
Manual and machinery descriptions
Tag of standard configuration
Generator Set Performance:
Voltage Regulation
Maintains voltage output to within ±1.0%
At any power factor between 0.9 and 1.0
At any variations from no load to full load.
At any variations from cold to hot.
At speed droop variations up to 4.5%
Frequency Regulation
Isochronous under varying loads from no
load to 100% full load when electronic is
fitted
Random Frequency Variation
Will not exceed±0.25% of its mean value
For constant loads no load to full load.
Waveform
Total harmonic distortion open circuit
Voltage waveform in the order of 1.8%.
Three-phase balanced load in the order of
5.0%
Alternator Temperature Rise
Class H insulation.
Compliance Standards:
To BS4999/5000 pt 99,
VDE 0530,UTE5100,
NEMA MG1-22, CEMA,
IEC 34, CSAA22.2,
AS1359, BSS 5514,
ISO 3046 and ISO 8528
