| Screen |
32 inch WH 169 |
| Brightness |
1250cd/selective |
| Contrast Ratio |
70001depend on brightness |
| Resolution |
1336×768×RGB |
| Pixel Pitch |
0.511×0.511mm |
| Respond Time |
15ms |
| Viewing Angle |
Level170°/ Uprightness170° |
| size of appearance |
760.0 x 450.0 x 47.25 mm (WxHxD) |
| Display Area |
697.68 x 392.26 mm (WxH) |
| Interface |
VGADVI-D or S-video |
| type of connector |
LVDS |
| Power Supply Unit |
DC12V/20A |
| Power Consumption |
195W |
| Working Temperature |
-20 to+60 |
Function for Advertising display:
Media Formats: Movie, Vedio, Music, Photo and Txt
Support Memory: SD/ CF / USB (1.0,2.0)
Daily Timer: Daily timer and auto power on/off , with function of memory when cutting power.
Vedio system: PALNTSC
OSD Language: Chinese, English
Picture play: zoompanbackground music and slide show play.
Playback Mode: File and folder repeat - choose to repeat playback one file or all the files
Play type: Support the vertical, horizontal play type, customized LOGO and running letter
Memory protection: Memory card lock protection, CF card password protection
Optional function: Support the network or wireless function
Optional function: Support touch screen, VGA and AV port
