Electronical Flow Weigher - DCS-L Series

Scope of application:The incontinuous accumulating measurement of raw material such as food, grain, feed ,etc.
1、The imported sensor and pneumatic implementation mechanism makes the work reliable and the maintenance easy.
2、The implementation of filling and measure adopt the imported stainless steel, which make it use for a long period.
3、The filling position controlling system make the production process smooth without the interruption of operator.
4、It has the advantage of smaller floor area, convenient operation and plastic coating.
5、The predetermined printer interface can  print the cumulative total of the number.

Technology Parameter
Specification	DCS-30L	DCS-50L	DCS-100L	DCS-300L
Weighing Extent	30kg	50kg	100kg	300kg
capability Measurement	≥ 10T/h	≥ 18T/h	≥ 36T/h	≥ 100T/h
high Install	2100mm	2100mm	2500mm	3000mm
Power Expenditure Air Expenditure	AC 220V 70W 0.3～0.5Mpa
the apparent size(mm)	790* 857* 　1385	790* 857* 　1485	810 *867 * 　1685	1000* 1000* 　2500
